Descrizione
Bike Geometry
- Bottom bracket drop [mm]: 40 mm
- Chain stay length [mm]: 435 mm
- Fork offset [mm]: 531 mm
- Fork total length [mm]: 44 mm
- Head tube angle: 66 degrees
- Head tube length [mm]:
- · 85 mm
- · 90 mm
- · 100 mm
- · 110 mm
- Reach [mm]:
- · 415 mm
- · 440 mm
- · 460 mm
- · 485 mm
- Stack [mm]:
- · 584 mm
- · 589 mm
- · 598 mm
- · 608 mm
- Seat tube angle: 74.5 degrees
- Seat tube length [mm]:
- · 390 mm
- · 430 mm
- · 470 mm
- · 510 mm
- Top tube length [mm]:
- · 575 mm
- · 602 mm
- · 624 mm
- · 651 mm
- Wheelbase [mm]:
- · 1134 mm
- · 1162 mm
- · 1185 mm
- · 1214 mm
Brake system
- Brake Rear Mount: Post Mount
- Brake Front Description: Sram, Freno a disco idraulico, Level Bronze Stealth 2 pistons, 180 mm
- Brake Rear Description: Sram, Freno a disco idraulico, Level Bronze Stealth 2 pistons, 160 mm
- Brake Lever Description: Sram, Level Bronze Stealth-BL
- Brake Rotor Description: Sram, Centerline X 180 / 160 mm, 6 bolt Disc
Drivetrain
- Cassette Teeth: 10-52T
- Crank Arm length:
- · 170
- · 175
- Crankset Teeth: 34T
- Crankset Type: single
- Number Of Gears: 12
- Bottom Bracket Description: Sram, PressFit, DUB PF 92 MTB Wide
- Cassette Description: Sram, Cassette, XS-1275 T-TYPE, 12s, XD
- Chain Description: Sram, Chain, GX T-TYPE 12s
- Chain Guide Description: Lapierre, 1x
- Crankset Description: Sram, GX EAGLE T-TYPE DUB
- Derailleur Rear Description: Sram, GX EAGLE AXS T-TYPE 12s
- Gear Description: Sram, Derailleur
- Pedal Description: XLC, by VP
- Shifter Left Description: Sram, Triggershift, AXS Pod 12s
- Shifter Right Description: Sram, Triggershift, AXS Pod Controller 12s
Frame and more
- Framesize Convection:
- · S
- · M
- · L
- · XL
- Max loadable weight (KG): 120 kg
- Front Fork Type: Suspension
- Suspension Type: Fully
- Travel Front: 120 mm
- Front Fork Description: FOX Factory, 34 Float SC Factory GRIP SL Remote 2Pos 15x110 120 mm
- Frame Description: MTB Fully, Carbonio, Uomo
- Shock Description: FOX Factory, Float Factory Remote 2pos 210x55mm 25x8mm/15x8mm
Handlebar and Saddle
- Handlebar Diameter: 31.8 mm
- Handlebar Material: Alluminio
- Handlebar Rise: 15
- Handlebar Width: 760 mm
- Seatpost Material: Alluminio
- Seatpost Travel (mm):
- · 100 mm
- · 125 mm
- Stem Length:
- · 60 mm
- · 70 mm
- Handgrip Description: Lapierre, grips small diameter
- Handlebar Description: Race Face, Flat bar, TURBINE, Rise: 15 mm, Ø: 31.8 mm
- Headset Description: Fsa, Integrated, Integrated 1.5ZS IS-2 /42/ACB hidden set
- Saddle Description: Fizik, Argo Vento X 140 mm
- Seatpost Description: Limotec, Dropperpost, A1 Light dropper, Ø: 31.6 mm, travel: 100 mm
- Stem Description: Lapierre, Alloy 7050, -6°, Ø: 31.8 mm, L: 60 mm
Wheels and wheel components
- Wheelset Material: Carbonio
- Wheel Size: 29
- Tyre Description: Maxxis, Ardent Race 3C MaxxSpeed EXO TR 2.35 120 TPI
- Tyre Rear Description: Maxxis, Rekon Race 3C MaxxTerra EXO TR 2.35 120 TPI
- Wheelset Description: Lapierre, XC SL carbon
- Wheelset Rear Description: Lapierre, XC SL carbon
- Wheelsize Description: 29, 29
* The illustration above is an example. We reserve the right, as long as the type, suitability and purpose of the bike is not reduced, to replace individual parts with components of the same or higher quality, so that the bike is delivered differently. The use of other components is currently mainly caused by delivery problems due to the Corona pandemic.
